The Cross-Belt Magnetic Separator employs a robust magnetic field to efficiently separate ferrous contaminants from a variety of materials. This equipment is equipped with high-strength magnets, strategically positioned to attract and capture magnetic and weak magnetic particles. Its adjustable settings cater to different material compositions, ensuring precise separation. With a focus on technical precision, it enhances the quality of end products by significantly reducing magnetic impurities.

Engineered for performance, the Cross-Belt Magnetic Separator is the ideal solution for reliable, high-efficiency ferrous metal separation in demanding industrial environments. With customizable conveyor widths ranging from 500 mm to 2000 mm, this system easily adapts to a wide variety of processing lines — from recycling plants to mineral processing facilities. At the heart of the system lies a powerful magnetic core, available with high-grade neodymium (NdFeB) or durable ceramic magnets, delivering exceptional separation performance across a magnetic field range of 100 to 400 mm. Whether you’re dealing with fine particles or bulky scrap, metals are effortlessly extracted without interrupting your material flow. Built for endurance, the separator is fitted with heavy-duty rubber or PVC belts, specially selected for maximum wear resistance and minimal maintenance. The drive system is powered by energy-efficient motors ranging from 0.75 kW to 5.5 kW, equipped with frequency inverters for precise control and adaptable operation. Designed for automatic, continuous operation, this separator minimizes downtime and maximizes productivity, offering a seamless solution for facilities that demand both quality and consistency.

Cross-Belt Magnetic Separator - Technical Selection Table

Model Magnetic Field Intensity (mT) Belt Width (mm) Belt Speed (m/s) Suspension Height (mm) Processing Capacity (tons/hour) Motor Power (kW) Approx. Weight (kg)
CBS-400 800 400 1.2 150 5 1.1 800
CBS-500 800 500 1.2 180 10 1.5 1000
CBS-600 1000 600 1.5 200 15 2.2 1300
CBS-750 1000 750 1.5 220 25 3 1800
CBS-900 1200 900 1.5 250 35 4 2500
CBS-1000 1200 1000 1.8 250 45 5.5 3000
CBS-1200 1200 1200 1.8 280 60 7.5 3800
CBS-1400 1300 1400 2.0 300 80 11 4500
CBS-1600 1300 1600 2.0 320 100 15 5500
CBS-1800 1500 1800 2.2 350 120 18.5 6500
CBS-2000 1500 2000 2.2 350 140 22 8000
CBS-2200 1500 2200 2.5 380 160 30 9500
CBS-2400 1500 2400 2.5 400 180 37 11000
CBS-2600 1500 2600 2.5 400 200 45 13000
CBS-3000 1500 3000 2.5 450 250 55 15000



NOTE: Our company manufactures systems in a wide range of capacities, from laboratory scale to industrial scale. To receive a price quote for your desired capacity, please send an email to
