LESS AGGLOMERATION
In the mining industry, achieving high efficiency and low energy consumption is always a top priority. The Wet Grinding System offers significant advantages in both energy efficiency and processing capacity. Unlike dry grinding, the wet grinding process provides superior flow properties and reduced agglomeration rates, resulting in finer and more uniform particles. By using water in the grinding process, the Wet Grinding System ensures better flow characteristics, leading to higher throughput in continuous mill feeds. With lower energy consumption, it delivers a higher production capacity compared to dry grinding.
The wet grinding process enables the production of finer particles, making it ideal for mineral separation applications. The high agglomeration rates encountered in dry grinding are significantly reduced, resulting in a more homogeneous product. Additionally, the maintenance and control systems of the Wet Grinding System are more cost-effective and easier to manage than those of dry grinding machines. Prior to mineral separation, the Wet Grinding System is preferred for its low energy consumption and high efficiency. Water-based grinding ensures lower energy consumption compared to dry grinding and facilitates more efficient particle movement within the system. This leads to reduced operational costs and a more sustainable production process, providing businesses with a competitive edge.
Model | Drum Diameter (mm) | Drum Length (mm) | Capacity (tons/hour) | Rotating Speed (RPM) | Motor Power (kW) | Approx. Weight (kg) |
---|---|---|---|---|---|---|
WG-900 | 900 | 1800 | 0.8 – 1.5 | 26 | 11 | 4500 |
WG-1200 | 1200 | 2400 | 1.5 – 3 | 23 | 22 | 8000 |
WG-1500 | 1500 | 3000 | 3 – 6 | 20 | 37 | 13000 |
WG-1800 | 1800 | 3600 | 5 – 10 | 18 | 55 | 19000 |
WG-2000 | 2000 | 4000 | 7 – 14 | 16 | 75 | 25000 |
WG-2200 | 2200 | 4500 | 9 – 18 | 15 | 90 | 32000 |
WG-2400 | 2400 | 5000 | 11 – 22 | 14 | 110 | 40000 |
WG-2600 | 2600 | 5200 | 13 – 26 | 13 | 132 | 50000 |
WG-2800 | 2800 | 5600 | 15 – 30 | 12 | 160 | 60000 |
WG-3000 | 3000 | 6000 | 18 – 36 | 11 | 185 | 70000 |
WG-3200 | 3200 | 6400 | 20 – 40 | 10 | 220 | 80000 |
WG-3400 | 3400 | 6800 | 23 – 46 | 9 | 250 | 90000 |
WG-3600 | 3600 | 7200 | 26 – 52 | 8 | 280 | 100000 |
WG-3800 | 3800 | 7600 | 30 – 60 | 7 | 315 | 110000 |
WG-4000 | 4000 | 8000 | 35 – 70 | 6 | 355 | 120000 |
NOTE: Our company manufactures systems in a wide range of capacities, from laboratory scale to industrial scale. To receive a price quote for your desired capacity, please send an email to
info@proses-makina.com
