Sub-aeration flotation machines operate on a unique mechanism where air is introduced below the liquid surface to facilitate efficient particle separation. The principle behind this technology is the controlled introduction of air, enabling precise adjustment of bubble size and distribution. Fine bubble formation enhances the contact area between bubbles and particles, significantly improving recovery rates even at low concentrations. At the core of the machine lies a high-efficiency aeration unit designed to generate optimally sized air bubbles. The high-pressure air intake system ensures fine bubble formation, increasing aeration efficiency and enhancing particle coating. This system incorporates modern compressor technologies and offers a range of capacity options to meet industrial demands.

One of the key advantages of sub-aeration flotation machines is their versatility. They are widely used across various industries, including mineral processing, wastewater treatment, and chemical manufacturing. This technology is particularly preferred for processing high-value ores containing minerals such as cobalt, nickel, and copper. By utilizing sub-aeration flotation, mining enterprises can enhance productivity while minimizing environmental pollution during production. Additionally, sub-aeration systems provide a stable operational environment, allowing for the efficient processing of materials with varying characteristics without requiring constant adjustments. Their adaptability and efficiency make them an essential solution for modern mineral processing and industrial applications.

Sub-aeration Flotation Cell - Technical Selection Table

Model Cell Volume (m³) Capacity (m³/min) Impeller Diameter (mm) Impeller Speed (RPM) Motor Power (kW) Air Flow Rate (m³/min) Approx. Weight (kg)
SA-100 1 0.3 – 0.6 400 280 5.5 0.4 1400
SA-200 2 0.6 – 1.2 500 260 7.5 0.8 2100
SA-300 3 0.9 – 1.8 600 240 11 1.2 2800
SA-400 4 1.2 – 2.4 700 220 15 1.6 3600
SA-500 5 1.5 – 3.0 800 200 18.5 2.0 4500
SA-600 6 1.8 – 3.6 900 180 22 2.4 5500
SA-700 8 2.4 – 4.8 1000 170 30 3.2 7000
SA-800 10 3.0 – 6.0 1100 160 37 4.0 8500
SA-900 12 3.6 – 7.2 1200 150 45 4.8 10000
SA-1000 14 4.2 – 8.4 1300 140 55 5.6 11500
SA-1100 16 4.8 – 9.6 1400 130 75 6.4 13000
SA-1200 18 5.4 – 10.8 1500 120 90 7.2 15000
SA-1300 20 6.0 – 12.0 1600 110 110 8.0 17000
SA-1400 22 6.6 – 13.2 1700 100 132 8.8 19000
SA-1500 25 7.5 – 15.0 1800 90 160 10.0 21000



NOTE: Our company manufactures systems in a wide range of capacities, from laboratory scale to industrial scale. To receive a price quote for your desired capacity, please send an email to
